Table of Contents
- INTRODUCTION
- What is Irradiance?
- Key factors to consider for Irradiance
- What is EMF?
- How much exposure is safe?
- Key factors to consider for EMFs
- INDEPENDENT, 3rd PARTY TESTING
- Testing conducted by ELECTROPOSSIBLE, UK
- Overall Findings
- MORE READINGS & IMAGES
- Images (Irradiance readings)
- Images (EMF readings)
- Image (Flicker reading)
What Is Irradiance?
Irradiance is defined as the flux of photons received by a unit area of a surface, measured in watts per square meter (W/m²) or in terms of our panels, in milliwatts per square centimeter (mW/cm²).
Irradiance is defined as the flux of photons received by a unit area of a surface, measured in watts per square meter (W/m²) or in terms of our panels, in milliwatts per square centimeter (mW/cm²).
Key factors to consider for Irradiance
✔ The higher the irradiance, the deeper the penetration
✔ Most clinical trials use 18 mW/cm² to 40 mW/cm² irradiance
✔ 30 degree beam angle preserves irradiance at greater distances
What is EMF?
According to the National Institute of Environmental Health Sciences, Electric and magnetic fields (EMFs) are invisible areas of energy, often called radiation, that are associated with the use of electrical power and various forms of natural and man-made lighting.
According to the National Institute of Environmental Health Sciences, Electric and magnetic fields (EMFs) are invisible areas of energy, often called radiation, that are associated with the use of electrical power and various forms of natural and man-made lighting.
How much EMF exposure is safe?
Based on studies done by the World Health Organization and the International Commission On Non-Ionizing Radiation Protection, the safe exposure limit for EMF radiation for prolonged periods is typically set at 0.08 µT (microteslas) for residential areas and 0.4 µT for occupational settings.
Based on studies done by the World Health Organization and the International Commission On Non-Ionizing Radiation Protection, the safe exposure limit for EMF radiation for prolonged periods is typically set at 0.08 µT (microteslas) for residential areas and 0.4 µT for occupational settings.
Key factors to consider for EMFs
✔ All electrical appliances emit EMFs
✔ Our homes and offices have some ambient EMF exposure
✔ EMF decreases rapidly with distance from the device
Independent, 3rd Party Testing
ELECTROPOSSIBLE LTD
Fully accredited electrical experts based in Milton Keynes, United Kingdom.
Website: electropossible.co.uk
Overall Findings
| MINI | COMPACT | MAX | ULTRA | ELITE | ||
|---|---|---|---|---|---|---|
| Irradiance (Spectrometer HP350IR) mW/cm² |
6" | 98.7 | 99.0 | 100.53 | 119.28 | 121.62 |
| 12" | 84.1 | 86.0 | 86.9 | 97.58 | 102.23 | |
| 24" | 59.0 | 63.2 | 68.65 | 71.77 | 74.91 | |
| 36" | 42.7 | 47.2 | 49.1 | 49.73 | 66.35 |
| MINI | COMPACT | MAX | ULTRA | ELITE | ||
|---|---|---|---|---|---|---|
| EMF (Cornet EMF Device) μT |
3" | ≈0.04 | ≈0.04 | ≈0.04 | ≈0.04 | ≈0.04 |
| 6" | ≈0.0 | ≈0.0 | ≈0.0 | ≈0.0 | ≈0.0 |
| MINI | COMPACT | MAX | ULTRA | ELITE | |
|---|---|---|---|---|---|
| Power Consumption (all LEDs at 100% intensity) Watts |
156 | 462 | 755 | 715 | 1552 |
| MINI | COMPACT | MAX | ULTRA | ELITE | |
|---|---|---|---|---|---|
| Decibel / Sound dB |
53 | 50.5 | 51 | 47 | 51 |
| MINI | COMPACT | MAX | ULTRA | ELITE | |
|---|---|---|---|---|---|
| Flicker | 0% | 0% | 0% | 0% | 0% |
More readings
Images (Spectrometer Irradiance readings)
The following images show real proof of a variety of Irradiance readings obtained at certain distances from our devices.
Please note: Even at a constant distance, Irradiance varies when measured from different parts of the panel. This happens because of LED placement and wavelength composition. You will notice that at larger distances, the variation reduces because multiple LEDs contribute more homogeneously toward to the readings.
Irradiance readings at 0"
Irradiance readings at 3"
Irradiance readings at 6"
Irradiance readings at 12"
Irradiance readings at 24"
Irradiance readings at 36"
| MINI | COMPACT | MAX | ULTRA | ELITE | ||
|---|---|---|---|---|---|---|
| Irradiance (Spectrometer HP350FR) mW/cm² |
6" | 98.32 | 110.57 | 125.96 | 133.76 | 139.18 |
| 12" | 86.29 | 95.43 | 107.84 | 117.15 | 128.36 |
| MINI | COMPACT | MAX | ULTRA | ELITE | ||
|---|---|---|---|---|---|---|
| Irradiance (Solar Power Meter) mW/cm² |
8" | 170 | 172 | 172 | 174 | 179 |
The following images show real proof of a variety of Irradiance readings obtained at certain distances from our devices.
Please note: Even at a constant distance, Irradiance varies when measured from different parts of the panel. This happens because of LED placement and wavelength composition. You will notice that at larger distances, the variation reduces because multiple LEDs contribute more homogeneously toward to the readings.
Irradiance readings at 0"
Irradiance readings at 3"
Irradiance readings at 6"
Irradiance readings at 12"
Irradiance readings at 24"
Irradiance readings at 36"
Images (EMF readings)
Image (Flicker reading)
